Product specifications
Acoustic properties (core)
Thickness 50 mm
- An acoustic core 50mm thick is required for damping down bass tones and reducing the number of decibels
Density 80 kg/m³
- High density = lots of mass
- High density + thickness 5 cm = our products are able to diminish all human sound frequencies by 100%
Finish
Aluminium frame
- Sturdy profiles of our own design
- 57 mm thick
- Powder-lacquered and so scratch-free
- Four colours available: RAL 9010 (warm white), RAL 9016 (traffic white), RAL 9006 (aluminium grey), 7021 (black)
Clamps
- Covers can be stretched tight
- Covers are replaceable
Molton
- Covers the acoustic filling
- Provides a smooth, even effect
- Trevira CS quality
End cover/tension in Trevira CS
- Stable branded fibre
- Not affected by variations in temperature and humidity: cover remains stretched flat
- 100% polyester
- Flame-retardant
Sublimation print
- Razor-sharp prints
- Longer colour fastness
- Cover remains acoustically open (as opposed to inkjet print
Technical properties
Acoustic value
NRC 0.95; α value 1
Fire class
Filling A1, canvas B-s1-d1
Weight
10 kg/m²
Thickness
Acoustic core of 50 mm, total panel thickness with frame = 57 mm
Acoustic filling
Mix of stone wool and glass wool
Canvas
100% polyester (Trevira CS)
